This time, I would like to record the basic settings used to recreate my “Sine Wave Version” sound.
This is not a preset designed for one specific sampler. Instead, it is a JSON-based description of the sound structure: a 440 Hz sine wave, two layers, amplitude envelopes, key-range-based panning, and loop settings.
If you give this JSON to a generative AI tool, it should be able to translate the specification into setup instructions for the sampler you normally use, such as Kontakt, Logic Sampler, UVI Falcon, or other sample-based instruments.
I cannot guarantee that the result will sound exactly the same in every sampler. However, the basic structure is very simple, so I believe a similar sound can be recreated in many sampler environments.
This is also a small record of reproducibility.
Even if the sampler or software environment changes in the future, the sound can still be reconstructed as long as the basic structure is preserved.
This specification is provided as a technical record for reproducibility. It does not grant permission to create or distribute presets, sample libraries, plug-ins, or plug-in instruments that use my artist name, work titles, or release names in a misleading way.
JSON
{
"preset_name": "Sine Wave Version",
"sampler_settings": {
"source_sample": {
"waveform": "sine wave",
"frequency": "440 Hz",
"length": "5 seconds",
"root_key": "A3",
"description": "Import a 5-second 440 Hz sine wave into the sampler."
},
"polyphony": {
"recommended_value": 99,
"description": "Use the maximum stable polyphony value available in Logic Sampler."
}
},
"layers": [
{
"name": "Layer 1",
"role": "main sustained sine wave layer",
"volume": "0 dB",
"amp_envelope": {
"attack": "5 ms",
"hold": "0 ms",
"decay": "4000 ms",
"sustain": "-inf dB",
"release": "400 ms"
},
"loop": {
"enabled": true,
"mode": "Forward",
"snap_zero_crossing": true,
"description": "Loop is enabled only for Layer 1."
}
},
{
"name": "Layer 2",
"role": "short secondary sine wave layer",
"volume": "-15 dB",
"amp_envelope": {
"attack": "5 ms",
"hold": "0 ms",
"decay": "200 ms",
"sustain": "-inf dB",
"release": "50 ms"
},
"loop": {
"enabled": false
}
}
],
"key_mapping_groups": [
{
"key_range": {
"low": "C-2",
"high": "B1"
},
"pan": -10,
"volume": "0 dB"
},
{
"key_range": {
"low": "C2",
"high": "B2"
},
"pan": -5,
"volume": "0 dB"
},
{
"key_range": {
"low": "C3",
"high": "B3"
},
"pan": 0,
"volume": "0 dB"
},
{
"key_range": {
"low": "C4",
"high": "B4"
},
"pan": 5,
"volume": "0 dB"
},
{
"key_range": {
"low": "C5",
"high": "G8"
},
"pan": 10,
"volume": "-5 dB"
}
],
"notes": [
"Layer 1 uses a looped 5-second 440 Hz sine wave for sustained playback.",
"Layer 2 is used as a quieter secondary layer without looping.",
"Panning is divided by key range, moving gradually from the left in the low register to the right in the high register.",
"The high register from C5 to G8 is reduced by 5 dB to avoid excessive brightness."
]
}
